Churchill 6 MK3.1 - July'16 - Dec'18

Below you will find exploded diagrams of the Churchill 6 MK3.1 spare parts, this stove was available between July 2016 and December 2018.

The main difference between the MK3 and MK3.1 models of the Churchill 6 is the size of the glass, which is larger on the Mk3.1, the other easy to spot difference is whether the ashpan has a seal on it or whether the door seals the ashpan (see door image for a visual explanation).

There are multiple images and you can use the buttons at the top to switch between them.

When you have found the correct part, click on the corresponding number and you will be taken to the part page where you can add the item to your cart.

There is also a full listing of all the parts below the diagrams.

Standard Convection Logstore Door Brick Set

Spare Parts

Brick Set

Lox - Ch 6kw Baffle set
M90029-02-26-99-00

£39.00

Lox, Ch 6kw mk3 Side Brick set
M90029-02-24-99-02

£52.00

Side Brick set comprises of left, right, and front left side brick.
Log Retainer - Churchill
M90520-04-00-00-00

£33.00

Log retainer wing for 5,6,8kW models.
Support Bracket - 6kW MK3
M90600-02-41-00-04

£16.00

Cleaning Hatch MK3
M90500-07-08-00-02

£30.00

This is suitable for all MK3 models.
