Churchill 8 MK4 - April'19 onwards

Below you will find exploded diagrams of the Churchill 8 MK4 spare parts, this stove was available from April 2019 onwards.

This stove is different to the MK3 models as it has a 'hammerhead' end to the air control lever.

There are multiple images and you can use the buttons at the top to switch between them.

When you have found the correct part, click on the corresponding number and you will be taken to the part page where you can add the item to your cart.

There is also a full listing of all the parts below the diagrams.

Stove Door Brick Set

Spare Parts

Fire Bricks

Full Brick Set - 8kW MK4
M90030-02-00-99-07
Next Available Date: 22/07/2021 subject to availability

£120.00

Suitable for the Loxton 8 MK4 and Churchill 8 MK4
Baffle Brick Set - 8kW MK4
M90030-02-26-99-02
In Stock, Ready to Order

£41.00

Suitable for the Loxton 8 MK4 and Churchill 8 MK4
Lox, Ch, Woodland 5kW mk4 Rear Pair Brick set
M90028-02-23-99-03
In Stock, Ready to Order

£47.00

Side/Front Brick Set - 8kW MK4
M90030-02-24-99-04
Next Available Date: 22/07/2021 subject to availability

£67.00

Suitable for the Loxton 8 MK4 and Churchill 8 MK4
Universal Cast Iron Grate - Mendip Mk.3 & 4
M90065-05-01-00-00
Next Available Date: 12/07/2021

£48.00

Cast Iron Grate Extender
M90065-05-04-00-00
In Stock, Ready to Order

£17.00

Churchill 5/8 MK4 Log Retainer Wing
M90520-04-00-00-01
In Stock, Ready to Order

£50.00

Upper Turbulence Plate - Mk.4 - 5 kW
M90500-02-64-00-04
In Stock, Ready to Order

£46.00

Rear Flue Cleaning Hatch - 5kW Mk.4
M90500-07-08-00-03
In Stock, Ready to Order

£30.00

MP MK4 Fire Brick Retaining Bracket (Front Side Right)
M90500-02-81-99-00
In Stock, Ready to Order

£14.00

Rope Seals

Door Rope Seal - Chur. 8 MK4
M10820-06-02-01-04
Next Available Date: 22/07/2021 subject to availability

£23.00

Glass Rope Seal - Churchill 8 MK4
M10820-01-02-01-04
Next Available Date: 22/07/2021 subject to availability

£12.00

Flue Collar Rope Seal - 150mm Diameter
M90800-07-10-01-00
In Stock, Ready to Order

£12.00

Furnace Door

Churchill 8 MK4 - Complete Door
M90820-06-00-00-05
Next Available Date: 22/07/2021 subject to availability

£367.00

Churchill 8 MK4 - Door Only
M90820-06-01-00-05
Next Available Date: 28/06/2021

£270.00

Door Rope Seal - Chur. 8 MK4
M10820-06-02-01-04
Next Available Date: 22/07/2021 subject to availability

£23.00

Churchill 8 MK4 Glass
M10820-01-01-99-04
Next Available Date: 22/07/2021 subject to availability

£147.00

Glass Rope Seal - Churchill 8 MK4
M10820-01-02-01-04
Next Available Date: 22/07/2021 subject to availability

£12.00

Churchill 8/10 MK4 Glass Clamp Kit
M90083-01-08-99-03
Next Available Date: 22/07/2021 subject to availability

£22.00

MP Churchill Mk3 Door Handle Fixings
M90520-06-13-99-00
In Stock, Ready to Order

£40.00

Churchill 8/10 MK4 Hinge Rod Fixing Kit
M90820-06-01-00-04
Next Available Date: 22/07/2021 subject to availability

£74.00

Loxton / Churchill MK4 Door Handle Latch Kit
M90520-06-12-99-01
In Stock, Ready to Order

£15.00

Ash Pan

Ash Pan
M90820-03-00-00-01
In Stock, Ready to Order

£31.00

Suitable for Churchill 8 MK4 & Woodland Large

Collar

Flue Collar (150mm)
M90800-07-06-00-02
In Stock, Ready to Order

£20.00

Flue Collar Rope Seal - 150mm Diameter
M90800-07-10-01-00
In Stock, Ready to Order

£12.00

Top Plate

Churchill 8 MK4 Top Plate
M10820-22-01-00-04
In Stock, Ready to Order

£113.00

Churchill 8 Convection MK4 Top Plate
M10822-22-01-00-04
In Stock, Ready to Order

£119.00

Flue Cover Plate - Lox/Chu 8, 10 Mk3 / MK4
M90800-07-03-00-02
In Stock, Ready to Order

£19.00

178mm ⌀

Convection Panels

Convection Side Panels (PAIR) - Churchill 8/10 MK4
M90824-20-12-00-02
In Stock, Ready to Order

£105.00

Convection Side Panels (PAIR) - Churchill 8/10 Logstore MK4
M90826-20-12-00-02
Next Available Date: 22/07/2021 subject to availability

£287.00

Accessories

Mendip Stoves Heat Resistant Glove
M90070-48-00-00-01
Next Available Date: 14/07/2021

£25.00

Mendip Stoves Low VOC Paint - 400ml
M90101-25-00-00-02
In Stock, Ready to Order

£31.50

Air Control

Air Box - 8 / 10kW MK4
M90820-11-07-99-01
Next Available Date: 22/07/2021 subject to availability

£215.99

This air box is suitable for the Loxton 8 / 10, Churchill 8 / 10 and Woodland Large.
Mk4 Air Control Lever & Fixings
M90500-11-34-99-01
Next Available Date: 22/07/2021 subject to availability

£34.00

Heat Shield

Rear Heat Shield - Inner
M90800-20-03-99-01
Next Available Date: 22/07/2021 subject to availability

£24.00

Suitable for Loxton 8, Churchill 8 and Woodland Large
Rear Heat Shield - Outer
M90800-20-06-99-01
Next Available Date: 22/07/2021 subject to availability

£30.00

Rear Heat Shield - Collar
M90800-20-10-99-00
In Stock, Ready to Order

£15.00

Blanking Plate

Blanking Plate
M90800-07-02-00-03
Next Available Date: 22/07/2021 subject to availability

£16.00

Suitable for Mendip Stoves MK4 models with 150mm flue outlet.
Flue Collar Rope Seal - 150mm Diameter
M90800-07-10-01-00
In Stock, Ready to Order

£12.00
